Indication
Balloon dilatation of the stenotic portion of a coronary artery or bypass graft stenosis for the purpose of improving
Features
1. Semi-compliant balloon can be suitable for different digestive tract.
2. High pressure resistance material to ensure the safety of dilation.
3. Three distinct diameters at three separate pressures.
4. Separate guidewire and insufflation lumens.
Product Model
|
Model |
Order Number |
Balloon inflation OD (mm) |
Balloon Length (mm) |
Catheter length (mm) |
For Channel （mm） |
Recommend Guide Wire （inch） |
|
A |
MD-A-MB-2223-0655 |
6-7-8 |
55 |
2300 |
≥2.8 |
≤0.035 |
|
MD-A-MB-2218-0655 |
6-7-8 |
55 |
1800 |
|||
|
MD-A-MB-2223-0855 |
8-9-10 |
55 |
2300 |
|||
|
MD-A-MB-2218-0855 |
8-9-10 |
55 |
1800 |
|||
|
MD-A-MB-2223-1055 |
10-11-12 |
55 |
2300 |
|||
|
MD-A-MB-2218-1055 |
10-11-12 |
55 |
2300 |
|||
|
MD-A-MB-2223-1080 |
10-11-12 |
80 |
2300 |
|||
|
MD-A-MB-2223-1255 |
12-13.5-15 |
55 |
2300 |
|||
|
MD-A-MB-2223-1555 |
15-16.5-18 |
55 |
2300 |
|||
|
MD-A-MB-2223-1580 |
15-16.5-18 |
80 |
2300 |
|||
|
MD-A-MB-2223-1855 |
18-19-20 |
55 |
2300 |
|||
|
MD-A-MB-2218-1855 |
18-19-20 |
55 |
1800 |
|||
|
MD-A-MB-2223-1880 |
18-19-20 |
80 |
2300 |
|||
|
C |
MD-C-DB-2219-0640 |
6 |
40 |
1900 |
≥2.8 |
≤0.035 |
|
MD-C-DB-2219-0840 |
8 |
40 |
1900 |
|||
|
MD-C-DB-2219-1040 |
10 |
40 |
1900 |
|||
|
MD-C-DB-2219-1240 |
12 |
40 |
1900 |
|||
|
MD-C-DB-2219-1440 |
14 |
40 |
1900 |
|||
|
MD-C-DB-2219-1260 |
12 |
60 |
1900 |
